# REDDEV Music
## Overview
REDDEV Music is an optional REDDEV Development Tablet addon for portable world audio, REDDEV tablet controls, and boombox placement powered by xSound.
## Features
* Optional REDDEV Dev Tablet app registration.
* Single `REDDEV Music` tablet app.
* Boombox item support for QBCore/Qbox, ox\_inventory, and ESX setup examples.
* Portable speaker prop placement, pickup, removal, and distance cleanup.
* Vehicle playback mode when the boombox is used inside a vehicle.
* Player, vehicle, fixed-location, and boombox emitter modes.
* xSound world audio with volume and range controls.
* URL playback, saved tracks, queue, favorites, recent tracks, playlists, loop, and shuffle.
* YouTube metadata through oEmbed.
* Optional resolver endpoint for converting YouTube URLs to direct audio streams.
## Dependencies
* `xsound` is a manifest dependency.
* `reddev_devtablet` for optional tablet app display.
* `oxmysql` is loaded in server scripts for optional SQL-backed expansion.
* Streamed speaker prop `qua_jblspeaker`.
## Installation
* Place `reddev_music` beside `reddev_devtablet`.
* Start `xsound` before `reddev_music`.
* Add the `boombox` item to your inventory using `ITEMS.md`.
* Copy `reddev_music/items/boombox.png` into your inventory image folder.
* Review `config.lua` for framework, boombox model, categories, locale, and tablet resource name.
* Use `/reddevmusic` or the REDDEV tablet icon to test the app.
## Server.cfg Ensure Order
```cfg
ensure xsound
ensure reddev_devtablet
ensure reddev_music
```
## Configuration
* `config.lua` controls `ReddevMusic.boomboxModel`, `ReddevMusic.framework`, prompt beep behavior, music categories, language, locale strings, and `Config.TabletResource`.
* `Config.TabletResource` defaults to `reddev_devtablet`.
* `ITEMS.md` contains QBCore/Qbox, ox\_inventory, and ESX item examples.
* `Config.ResolverEndpoint` is documented in README as the optional resolver hook, but no active assignment was found in `config.lua`.
## Commands
* `/reddevmusic` opens the REDDEV Music tablet app.
* The README/INSTALL mentions `/boombox`, but no `RegisterCommand('boombox')` was found in the scanned current source. Treat boombox as a usable item unless you add a command yourself.
Public exports detected:
* `Open`
* `GetSnapshot`
Public/admin events detected:
* None documented as customer/admin entry points.
## Items
* `boombox` is the portable speaker item.
* Image path: `reddev_music/items/boombox.png`.
* ox\_inventory image target: `ox_inventory/web/images/boombox.png`.
## Permissions
* No ACE, job, gang, identifier, or admin group checks were found for basic use.
* Access is controlled by who has or receives the `boombox` item and who can access the tablet app.
## Inventory Support
* QBCore/Qbox item example in `ITEMS.md`.
* ox\_inventory item example in `ITEMS.md`.
* ESX legacy SQL item example in `ITEMS.md`.
* README mentions qb-inventory, ox\_inventory, and qs-inventory image folders.
## Framework Support
* `ReddevMusic.framework = 'qb'` by default.
* `ReddevMusic.framework = 'esx'` is documented as the other config option.
* Qbox can use the QBCore/Qbox item setup block, but no separate Qbox framework value was found.
## Target Support
* No target integration was found. Boombox world interaction uses key prompts.
## Database or SQL Setup
* SQL file: `install/reddev_music.sql`.
* The install guide says the current music library stores local player library state with resource KVP storage.
* The SQL file is described as optional tables and item snippets for future SQL-backed expansion.
## Troubleshooting
* If the app icon is missing, confirm `reddev_music` is started and restart `reddev_devtablet`.
* If music does not play, confirm `xsound` is started before `reddev_music`.
* If the item does not work, confirm the `boombox` item exists and its image was copied.
* If YouTube URLs fail, configure a resolver endpoint that returns the README's expected JSON contract.
* If `/boombox` does not work, the scanned code does not register that command; use the item or add a command.
## FAQ
* **Is REDDEV Music required for the tablet?** No. It is optional and the icon appears only while the resource is started.
* **Does it require xSound?** Yes. `xsound` is a manifest dependency.
* **Does it consume the boombox item?** Server code includes add/remove handlers for the `boombox` item; test your inventory path after setup.
---
